1000kW Diesel Generator Sets | Prime & Backup Power Solutions
A 1MW generator project is a significant undertaking that benefits from a single-source, responsible supplier. We manage the entire process, from fault current analysis to final commissioning and operator training. To receive a complete project dossier and discuss financing options, please use the dedicated contact form for mega-watt projects below.
1000kw general specs
| Parameter | Value | Note |
| Prime Power | 1000 kW / 1250 kVA | Allow 24-hour continuous operation |
| Standby Power | 1100 kW / 1375 kVA | Emergency use only(1h/12h) |
| Rated Voltage | 400V / 230V | customizable：380V - 480V |
| Frequency | 50 Hz | optional 60 Hz (1800 RPM) |
| Phase / Wire | 3 Phase, 4 Wires | three-phase four-wire |
| Power Factor | 0.8 (Lagging) | lag |
| Rated Current | Approx. 1800 A | The customer needs to provide cables |
comparison of 1000kw core engine brands
| Feature | Cummins Option | Perkins Option | Yuchai/Weichai Option |
| Engine Model | KTA50-G3 / KTA38-G5 | 4008-30TAG2 | YC12VTD / 12M55 |
| Cylinders | V-16 or V-12 | 8-L (Inline) or V-12 | V-12 |
| Aspiration | Turbocharged & Aftercooled | Turbocharged & Air-to-Air | Turbocharged & Intercooled |
| Governor Type | Electronic (ECM) | Electronic (ECM) | Electronic (ECU) |
| Fuel Cons. @100% Load | Approx. 260 L/h | Approx. 255 L/h | Approx. 250-260 L/h |
| Advantage | Best Durability & Parts | Best Stability & Noise | Best Price & Value |
1000kw generator tco comparison & seletion guide
| Comparison Dimension | Cummins 1000kW | Perkins 1000kW | Yuchai 1000kW | SDEC 1000kW | Notes / Calculation Basis |
| Estimated Initial Investment | $225000 | $223000 | $129000 | $116800 | For standard skid-mounted configuration. |
| Fuel Consumption @ 100% Load (L/h) | ~205 | ~210 | ~215 | ~218 | Major driver of operational cost. Based on engine spec sheets. |
| Avg. Annual Maintenance Cost | ~2.5% | ~2.8% | ~3.0% | ~3.2% | Percentage of initial investment (parts & labor). |
| Major Overhaul Interval (hours) | 30,000 | 28,000 | 25,000 | 24,000 | Indicator of long-term durability and design life. |
| Estimated 5-Year TCO | [Auto-Calc] | [Auto-Calc] | [Auto-Calc] | [Auto-Calc] |
international emissions compliance & certification
| Certification / Standard | Cummins | Perkins | Yuchai | SDEC | Key Target Markets |
| EPA Tier 4 Final | Standard | Standard | Optional | Typically Not Offered | North America (USA, Canada), other regulated regions. |
| EU Stage V | Standard | Standard | Optional | Typically Not Offered | European Union, United Kingdom. |
| China National Phase IV (国四) | Optional | Optional | Standard | Standard | Mainland China. |
| GCC / GSO Conformity | ✓ | ✓ | ✓ | ✓ | Gulf Cooperation Council countries (UAE, Saudi Arabia, etc.). |
| EPA Tier 2 / EU Stage II | (Base for Tier 4) | (Base for Tier 4) | Standard | Standard | Many developing markets, industrial zones with less strict rules. |
List of 1000kw diesel generator sets
1000kw diesel generator related issues
1. What is the average fuel consumption of a 1000kW diesel generator at different load levels?
Fuel efficiency is a critical factor for operational budgeting. Typically, a 1000kW generator consumes approximately 260–280 liters (68–74 gallons) per hour at 100% load. At 75% load, which is the common optimal operating range, consumption drops to roughly 190–210 liters (50–55 gallons) per hour. To maximize fuel economy, we recommend selecting a unit with electronic fuel injection and ensuring regular maintenance of the fuel filters and injectors.
Based on the actual load level of your diesel generator, you can click on the fuel consumption calculation page of the diesel generator set to calculate it
2. Can a 1000kW generator be used for Prime Power, or is it only for Standby use?
Our 1000kW units are available in both Standby and Prime ratings.
Standby Power (ESP): Designed for emergency use during utility power outages. It should not be overloaded and is typically rated for a maximum of 200–500 hours of operation per year.
Prime Power (PRP): Suited for continuous operation in areas without a reliable grid. It can handle variable loads for unlimited hours, usually with a 10% overload capacity available for 1 hour in every 12.
Please specify your application so our engineers can provide the correct engine configuration.- The unit consumption of diesel varies depending on the type of diesel engine used. If you have determined the unit consumption of a certain brand of diesel engine, please go to: Diesel Generator Fuel Calculator
3. What are the key ventilation and space requirements for installing a unit of this size?
A 1000kW generator generates significant heat and requires massive airflow for cooling and combustion. The installation site must have:
Air Intake & Exhaust: Sufficient louver space to prevent "short-circuiting" of hot air. The radiator discharge should be ducted directly to the outside.
Footprint: A reinforced concrete pad (foundation) capable of supporting the static weight (approx. 8,000–12,000kg) and absorbing dynamic vibrations.
Clearance: A minimum of 1.5 to 2 meters of clearance around the unit for maintenance access and safety compliance.
4. Does this 1000kW generator support synchronization with other units or the utility grid?
Yes, our 1000kW generators come equipped with advanced digital controllers (such as Deep Sea or ComAp) that support Parallel/Synchronized operation. This allows you to:
Link multiple units together to meet a total load exceeding 1000kW.
Implement "N+1" redundancy for critical data centers or hospitals.
Perform "Seamless Transfer" (Bumpless Transfer) back to the grid once utility power is restored, ensuring zero downtime for your facility.
- To learn more about technical support for grid connection of diesel generator sets, please go to
：the page of fully automatic diesel generator sets
